Spectrum PA6 Neat

PA6 Neat High temperature poliamide

A major feature of the PA6 Neat is its increased mechanical strength as compared to other plastics. The material also features exceptional thermal properties, chemical resistance and a relatively high resistance to corrosion stimulators. Poliamide Low Warp belongs to the few materials with low processing shrinkage, approx. 0.3%.

To attain the very attractive properties of PA6 Neat, as regards the technical aspects, you need to follow the basic storage rules for such materials (in a dry and dark place with humidity below 15%). To obtain the best parameters of the printed object possible, it is recommended to dry the material prior to work.

Key features:

  • exceptionally low processing shrinkage of 0.3%
  • a very wide temperature range for prolonged operation as well as a very high temperature up to 160°C for short-time operation
  • good tribological properties, including dry friction conditions such as in slide bearing
  • chemical resistance to lubricants and oils
  • an unusually good adhesion to 3D printer build platforms as compared to other Poliamide-based filaments on the market

Applications:

  • production of gear wheels and racks, slide bearings, sweep-off gears and guide rolls operated in elevated temperatures up to 120°C on a prolonged basis and up to 160°C on a short-time basis
  • all types of ring and plate seals with an increased chemical and corrosion resistance
  • end-use parts
  • tooling
  • functional prototyping
  • industrial modelling

Filament specification:

Filament diameter: 1.75mm   / 2.85mm

Density:  1.14g/cm3

Nozzle temperature: 240-270°C

Bed temperature: 80-100°C

Printing speed: 30-70mm/s

Heated chamber: recommended

Verify your spool option: YES
